Removal

Disconnect Alternator Cable and Connector

Click on the underlined sentence.
Set nut
Short-circuit prevention cover
  1. Disconnect alternator cable
  (1) Remove the alternator
cable set nut.
  (2) Disconnect the alternator cable.
HINT:
The alternator cable is wired directly from the battery, and has a short-circuit prevention cover at the terminal.

2. Disconnect alternator connector

(30)
