Installation

Install Combination Meter
Click on the underlined sentence.
Clip
Claw installation position (A type)
Claw installation position (B type)
  1. Install combination meter

2. Install combination meter cover
  (1) Align the combination meter cover with the clips and installation locations, then gently press by hand into position.

  (2) Install the clip.

(22/2)
